Plot Method for causalDisco Objects

Source: R/plot.R
plot.Rd

This is the generic plot() function for objects of class knowledge or disco. It dispatches to the class-specific plotting methods plot.Knowledge() and plot.Disco().

Arguments

x

An object to plot (class knowledge or disco).

...

Additional arguments passed to class-specific plot methods and to caugi::plot().

Value

Invisibly returns the input object. The primary effect is the generated plot.

See also

plot.Knowledge(), plot.Disco(), caugi::plot()

Examples

data(tpc_example)
kn <- knowledge(
  tpc_example,
  tier(
    child ~ starts_with("child"),
    youth ~ starts_with("youth"),
    old ~ starts_with("old")
  )
)
plot(kn)


cd_tges <- tges(engine = "causalDisco", score = "tbic")
disco_cd_tges <- disco(data = tpc_example, method = cd_tges, knowledge = kn)
plot(disco_cd_tges)
